SkyWalker-2312SL-1400KV-BLACK-G1-HW

Hobbywing SkyWalker-2312SL-1400KV-BLACK-G1-HW

The first generation of the 23-series Skywalker motors brings a whole new flying experience to RC hobby pilots with fixed-wing models. They are a suitable addition to the established Skywalker controllers and achieve around 10% more output power than comparable motors with similar specifications.

The Skywalker flight motors have a special propeller mount that provides a higher overall torque. And the motor, which is equipped with N48 magnets, uses this to provide maximum torque output. No problems due to overheating are to be expected, by the way. After all, there is a generous cavity in the motor, which, together with the self-discharging structure of the upper cover, increases the cooling capacity. And, together with other high-quality components such as the 0.2mm JNEH1200 silicon steel sheet and the high-temperature resistant enamelled wire, these motors are ready to travel the skies for a long time.

The rotor itself has been designed to significantly reduce potential motor vibrations and ensure smoother operation overall. The rotor is also secured in a combination of different components to further increase the reliability of Skywalker motors.

Features:

    Powerful motor
    Ideal as a complement to the Skywalker controllers
    Optimised rotor run
    Designed for effective cooling and heat dissipation
    18AWG silicone cable

Technical data:
Type:     Brushless
Speed: 1400KV
No-load current: 1.8A/14.8V
Resistance: 39.9m Ohm
Number of cells LiPo: 3-4S LiPo
Slots & poles: 12N14P
Max. continuous current: 37A/65s
Max. continuous power: 550W/65s
Phase wire: 18AWG, 100mm
Ball bearings: 684ZZ (D9 x d4 x 4)
Diameter: 28.8mm
Length: 46mm
Shaft diameter: 4mm
Weight: 65g
Recommended controller: Skywalker V2 30A-40A
Propeller:     3S: 7x6E, 8x6E
4S: 7x5E, 8x4E
Mounting thread: D:12mm-3 x M2.5
Base thread:     D:16mm-2 x M3
D:19mm-2 x M3
